Inspection - TIANLONG CYLINDER CHINA

Inspection Of TIANLONG LPG Cylinder

Key Tests For Quality Control

Hydraulic Test

Hydralic test are conducted by appling water pressure 34bar into the cylinder to reach designated pressure levels for a period of at least 30 seconds to detect for any possible leakage,bulging or distortion.
Tightness Test

By applying at least 18bar, compressed air pressure into the cylinder prior the immersing the cylinder completely in water to check for any possible leakage.
Bursting Test

Records the volume of the test fluid used, records the pressure at which the cylinder bursts,the volume of test fluid used between the time when the pressure starts to rise and at the time of bursting, or the difference between the volume of the cylinder at the beginning and the end of the test
Mechanical Test

Bending test is a test for cracks and any other non-conformance on welding surface. Tensive test is a mecanical test of parent metarial, circumferentialweld, and long itudinal weld of heart-treated cylinder to determine the tensile strength, yield strength and parentage of elongation

Test Pictures

Certification

Q What are the common inspection methods for steel cylinders?

A
①Hydralic Test ②Tightness Test ③Mecanical Test ④Radiographic Test(RT) ⑤Bursting Test
Q What services do you offer?

A We can customize the cylinders according to your requirements including the size,color, valve, and we can emboss your brand name for free.
Q How to ensure the quality of your bottles?

A
Our professional engineers who operate the quality standard system according to ISO9001, ISO14000，ISO18000, control a full set of testing equipment, guarantee the production quality; Invite the third party like SGS and BV to do the inspection in our own lab to make sure the Bottles meet the standard of different markets.
